Mitsubishi QD77MS2 MELSEC-Q Series Simple Motion Module (PN: 248702)

Name: Mitsubishi QD77MS2 MELSEC-Q Series Simple Motion Module (PN: 248702)
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original Mitsubishi Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

Q-Series Simple Motion Module; 2 Axes (SSCNET III/H)

Brand :
MITSUBISHI

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The QD77MS2 is a simple motion module from Mitsubishi Electric's MELSEC-Q series, designed specifically for Q-series PLCs. It features 2-axis control and SSCNET III/H high-speed fiber optic communication capabilities.

Material Number: 248702

High-capacity 5V output: Provides a 6A 5VDC output capacity, far exceeding the basic model (such as the Q61P's 3A), stably driving multiple expansion modules, high-load CPUs, and intelligent function modules.

High-speed network and multi-axis control: Equipped with an SSCNET III/H high-speed fiber optic communication network, it boasts strong anti-interference capabilities, supports up to 2-axis control, and simplifies wiring.

Rich advanced motion functions: Supports 2-axis linear/circular interpolation and includes advanced functions such as built-in synchronization control, electronic cams (automatically generated), and phase correction to meet complex trajectory motion requirements.

Ease of use at the positioning module level: Breaking away from the traditional high barrier to entry for motion controllers, complex motion control can be easily achieved through simple parameter settings and function block (FB) programming.

Superior vibration suppression: Utilizing vibration suppression control algorithms for 3-inertial frame machinery, it can simultaneously suppress two types of low-frequency vibrations, effectively reducing residual vibrations in the robotic arm or equipment body.

100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support Reliable Warranty

Technical Specifications

Series	MELSEC-Q SERIES
Type	SIMPLE MOTION MODULE
Command Interface	SSCNET III/H, SSCNET III
Number of Axes	2
Program Capacity	600
Program Capacity Unit	POSITIONING DATA/AXIS
Inputs	2

Conformity & Certifications

CE	COMPLIANT
UL / cUL	COMPLIANT
UKCA	COMPLIANT
Shipping Approvals	ABS, BV, DNV GL, LR, NK, RINA
EAC	NON-COMPLIANT

Why Source This Module From Us?

Genuine Guarantee: Guaranteed original Mitsubishi Electric product. We say no to counterfeits or refurbished parts, ensuring the absolute stability of your machinery.
Ready-to-Ship Inventory: Supported by a robust warehousing system, in-stock items are dispatched immediately upon order confirmation to minimize costly downtime.
End-to-End Support: From pre-sales model verification to after-sales wiring guidance, our engineering team ensures a hassle-free procurement process.
Competitive Pricing: Leveraging our strong supply chain network, we offer highly competitive pricing and exclusive discounts for bulk orders.

Applications

Multi-axis precision positioning: such as tool positioning in CNC machining centers, and X-Y axis linear and circular interpolation in dispensing and placement machines.
Synchronization and cam control: utilizing electronic gears and electronic cams to replace mechanical cams. Commonly used for synchronized cutting in packaging machines, color alignment in printing machines, and material synchronization in production lines in the food and beverage industry.
Speed and torque control: supporting continuous operation to torque control, commonly used for constant tension winding and unwinding in winding machines and wire drawing machines.
Logistics conveyor control: used for precise addressing of stacker cranes in automated warehouses, and for length and positioning control of high-speed sorting lines and variable frequency conveyor belts.

Engineer's Tip: It combines the high performance of a motion controller with the ease of use of a positioning module, easily achieving complex positioning, synchronization, and cam control.
