Mitsubishi Q00UCPU MELSEC-Q series entry-level high-performance general-purpose CPUs (PN: 221576)

Name: Mitsubishi Q00UCPU MELSEC-Q series entry-level high-performance general-purpose CPUs (PN: 221576)
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original Mitsubishi Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

PLC Q Series iQ CPU module; 1024 I/O; 80 ns/com.; 10k steps

Brand :
MITSUBISHI

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The Mitsubishi Q00UCPU is an entry-level, high-performance general-purpose CPU in the MELSEC-Q series.

Material Number: 221576

High-speed processing: Basic instruction processing speed reaches 80 ns, significantly shortening the scan cycle and meeting the needs of most high-speed production lines and automated equipment.

Large-capacity storage: Program capacity up to 10K steps (equivalent to 40K bytes of memory), capable of handling complex logic control and large-scale data processing.

Powerful I/O support: Supports up to 8192 I/O points, compatible with various expansion modules, easily meeting the needs of large and complex systems.

Multi-tasking: Supports concurrent execution of multiple tasks, efficiently handling background tasks such as communication and data acquisition while running the main control program.

Industrial-grade stability: Utilizes high-specification industrial-grade components, capable of withstanding harsh operating conditions such as high and low temperatures and strong vibration, ensuring continuous and stable operation 24/7.

High cost-performance ratio: As an entry-level U-series CPU, it is affordable and is the preferred choice for achieving high-precision industrial control at low cost.

100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support Reliable Warranty

Technical Specifications

Series	MELSEC-Q SERIES
Type	UNIVERSAL MODEL QCPU
Program Memory	10K
Program Memory Unit	STEPS
Local I/O Points	1024
Local + Remote I/O Points	8192
Cycle Time LD (ns)	80
Cycle Time MOV (ns)	160
USB	1
RS-232	1
Buffer Battery	YES
Int. Current Consumption (A)	0,33

Conformity & Certifications

CE	COMPLIANT
UL / cUL	COMPLIANT
UKCA	COMPLIANT
Shipping Approvals	ABS, BV, DNV GL, LR, NK, RINA
EAC	NON-COMPLIANT

Why Source This Module From Us?

Genuine Guarantee: Guaranteed original Mitsubishi Electric product. We say no to counterfeits or refurbished parts, ensuring the absolute stability of your machinery.
Ready-to-Ship Inventory: Supported by a robust warehousing system, in-stock items are dispatched immediately upon order confirmation to minimize costly downtime.
End-to-End Support: From pre-sales model verification to after-sales wiring guidance, our engineering team ensures a hassle-free procurement process.
Competitive Pricing: Leveraging our strong supply chain network, we offer highly competitive pricing and exclusive discounts for bulk orders.

Applications

Small and medium-sized packaging machinery: Leveraging its high-speed input/output response and compact size, it is widely used to control material handling, labeling, and sealing on packaging lines.
Logistics and assembly line control: Precisely schedules various conveyor lines, processes high-speed sensor signals, and achieves sorting and positioning.
Robot and multi-device collaboration: In automated workstations, it communicates with external devices (such as FANUC robots) via a Human-Machine Interface (HMI) for real-time fine-tuning of motion trajectories and position registers, as well as data transmission.
Data acquisition and communication expansion: Supports protocols such as Ethernet/IP and CC-Link, connecting to various intelligent functional modules, suitable for industrial IoT applications requiring host computer monitoring.

Engineer's Tip: With its high cost-effectiveness and compact size, it is ideal for small to medium-sized automated control systems such as packaging machinery and conveyor lines.
