SIEMENS 6ES7135-6HD00-0BA1 Analog output module for SIMATIC ET 200SP distributed I/O system

Name: SIEMENS 6ES7135-6HD00-0BA1 Analog output module for SIMATIC ET 200SP distributed I/O system
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original SIEMENS Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

Part Number	6ES7135-6HD00-0BA1
Product Type	Analog output module AQ 4xU/I ST
Product Origin	Germany
Shipping Port	Xiamen
Weight	0.031 kg

Brand :
Siemens

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The 6ES7135-6HD00-0BA1 is an analog output module (AQ 4xU/I ST) for the Siemens SIMATIC ET 200SP distributed I/O system.

The 6ES7135-6HD00-0BA1 is an analog output module (AQ 4xU/I ST) for the Siemens SIMATIC ET 200SP distributed I/O system. It provides four analog output channels, supporting both voltage and current signal types, suitable for precise control needs in various industrial automation scenarios. The module is only 15mm wide, with a compact design, and supports firmware updates and I&M identification data.

100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support 12-Month Warranty

Bosch Rexroth MS2N03-B0BYN-CMSG1-NNNNN-NN Servo Motor

Core Features

✓ 4-Channel Analog Output: Provides 4 outputs, supporting voltage (±10V, 0-10V, ±5V, 1-5V) and current (±20mA, 0-20mA, 4-20mA) signals.
✓ High-Precision Signal Output: Up to 16-bit resolution (including sign bit), with a basic error limit of ±0.3%.
✓ Comprehensive Diagnostic Functions: Integrated diagnostic alarms monitor power supply voltage, open circuit (current output), and short circuit (voltage output) faults.
✓ Fast Response and Isolation: Minimum cycle time of 5ms for all channels, and electrical isolation between channels and the backplane bus.

Technical Specifications

Brand	SIEMENS
Model / Part Number	6ES7135-6HD00-0BA1
Number of Output Channels	4 analog outputs
Output Signal Range	Voltage (±10V, ±5V, 0-10V, 1-5V); Current (±20mA, 0-20mA, 4-20mA)
Resolution	Up to 16 bits (including sign bit)
Load Impedance	Voltage output ≥2kΩ; Current output ≤500Ω
Power Supply Voltage	24V DC (19.2V to 28.8V)
Power Consumption	Typical 1.5W
Protection Rating	IP20
Dimensions (W x H x D)	15 x 73 x 58 mm
Applicable Base Units	BU type A0, A1

Frequently Asked Questions

Q: In what situations is this module typically used?

A: Primarily used in industrial automation where precise analog control of actuators (such as valve positioners, frequency converters, proportional valves, etc.) is required. Common applications include process control, speed/position control on production lines, and HVAC systems.

Q: When connecting a 4-20mA current output, what could be the reason if the output current does not reach 20mA?

A: The most common reason is that the total loop resistance exceeds the module's maximum drive capability (500Ω). If passive isolators or similar devices are connected in series in the loop, their voltage drop will further compress the available drive voltage, limiting the output. The solution is to calculate the total loop resistance or consider using an active isolator instead of a passive isolator.

Q: What types of base units can this module be used with?

A: It is compatible with BU type A0 and A1 base units. Specific compatible base units can be identified by the last two digits of the product number.
