SIEMENS 6ES7153-2BA10-0XB0 SIMATIC ET 200M Distributed I/O System IM 153-2 High-Performance Interface Module

Name: SIEMENS 6ES7153-2BA10-0XB0 SIMATIC ET 200M Distributed I/O System IM 153-2 High-Performance Interface Module
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original SIEMENS Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

Part Number	6ES7153-2BA10-0XB0
Product Type	ET 200M Distributed I/O Interface Module
Product Origin	Germany
Shipping Port	Xiamen
Weight	0.36 kg

Brand :
Siemens

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The 6ES7153-2BA10-0XB0 is the IM 153-2 high-performance interface module for the Siemens SIMATIC ET 200M distributed I/O system.

As a PROFIBUS DP slave, it can connect up to 12 S7-300 series I/O modules to the DP master system. This module supports redundant configuration and features high-precision timestamp functionality (up to 1ms accuracy), making it suitable for automation scenarios with high real-time and reliability requirements.

100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support 12-Month Warranty

Bosch Rexroth MS2N03-B0BYN-CMSG1-NNNNN-NN Servo Motor

Core Features

✓ PROFIBUS DP Slave Interface: Connects to the DP master station via RS485, supporting a maximum transmission rate of 12 Mbit/s.
✓ High Scalability and Redundancy: Supports up to 12 S7-300 modules with redundancy capabilities, improving system availability.
✓ High-Precision Timestamps: Timestamps changes in digital input signals with an accuracy of 1ms, facilitating fault diagnosis and event sequence analysis.
✓ SYNC/FREEZE Synchronization Function: Supports PROFIBUS DP's SYNC and FREEZE modes, enabling clock synchronization with the master bus.

Technical Specifications

Brand	SIEMENS
Model / Part Number	6ES7153-2BA10-0XB0
Supported Modules	Up to 12 S7-300 modules
Redundancy	Supported
Interface	PROFIBUS DP (RS485), 9-pin Sub-D
Maximum Transfer Rate	12 Mbit/s
Supply Voltage	24V DC (20.4V ~ 28.8V)
Maximum Current Consumption	650mA (with 24V DC supply)
Backplane Bus Power Supply Capability	5V DC / 1.5A
Power Consumption	Typical 5.5W
Protection Rating	IP20
Dimensions	40 x 125 x 117 mm
Operating Temperature	0°C to 60°C

Frequently Asked Questions

Q: What is the practical use of the 1ms timestamp function in this module?

A: It is mainly used to accurately record the sequence of events. When the digital input signal changes, the module records a timestamp accurate to 1ms. This is crucial for troubleshooting and analyzing chain reaction logic, especially suitable for applications requiring precise fault location.

Q: How many S7-300 I/O modules can this module support at most?

A: Up to 12. This reflects its "high-performance" characteristics, supporting more modules than standard models (such as the IM 153-1), making it suitable for distributed sites requiring a large number of signal points.

Q: Can it replace the non-redundant 6ES7153-1AA03-0XB0 module?

A: It cannot be directly replaced. The 6ES7153-2BA10-0XB0 supports redundancy, while the 6ES7153-1AA03-0XB0 does not. Their characteristics and application scenarios are different, and they cannot be simply interchanged.
