SIEMENS 6ES7441-2AA05-0AE0 SIMATIC S7-400 Series Point-to-Point Communication Processor (CP 441-2)

Name: SIEMENS 6ES7441-2AA05-0AE0 SIMATIC S7-400 Series Point-to-Point Communication Processor (CP 441-2)
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original SIEMENS Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

Part Number	6ES7441-2AA05-0AE0
Product Type	CP 441-2 Communication Processor
Product Origin	Germany
Shipping Port	Xiamen
Weight	0.80 kg

Brand :
Siemens

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The 6ES7441-2AA05-0AE0 is a point-to-point communication processor (CP 441-2) in the Siemens SIMATIC S7-400 series.

It is primarily used to extend the serial communication capabilities of the S7-400 CPU, exchanging data with printers, other controllers, or field devices through two variable communication interfaces. This module supports multiple standard protocols and can support user-specific protocols by loading drivers.

100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support 12-Month Warranty

Bosch Rexroth MS2N03-B0BYN-CMSG1-NNNNN-NN Servo Motor

Core Features

✓ Flexible serial communication: Provides two variable point-to-point connection channels, with optional RS 232C, 20mA (TTY), or RS 422/RS 485 interface modules as needed.
✓ Built-in multi-protocol support: Directly supports communication protocols such as 3964(R), ASCII, RK 512, and printer drivers.
✓ Expandable protocol drivers: Supports user-specific protocols such as Modbus RTU by loading drivers, enhancing its versatility.
✓ Integrated into STEP 7: Configuration and parameter settings can be performed directly in the STEP 7 software, simplifying the engineering configuration process.

Technical Specifications

Brand	SIEMENS
Model / Part Number	6ES7441-2AA05-0AE0
Number of Interfaces	2 (variable)
Supported Interface Types	RS 232C (V.24), 20 mA (TTY), RS 422/RS 485 (X.27)
Maximum Transfer Rate	115.2 kbit/s (RS 232 / RS 422 / RS 485)
Supported Protocols	3964 (R), ASCII, RK 512, Printer Driver, Modbus RTU (driver required)
Power Consumption	+5V DC backplane bus, maximum 300 mA
Power Dissipation	Typical 2.7 W
Dimensions	25 mm x 290 mm x 210 mm
Operating Temperature	0℃ to 60℃

Frequently Asked Questions

Q: What are the main applications of this module?

A: It's primarily used in scenarios where the S7-400 CPU needs to communicate with external serial devices, such as connecting a serial printer to print reports, or exchanging data with third-party instruments, frequency converters, etc., via the Modbus RTU protocol.

Q: Can I use this module to enable communication between my S7-400 and third-party devices via Modbus RTU?

A: Yes. This module supports communication with third-party Modbus devices by loading Modbus RTU master or slave drivers. You will need to purchase the corresponding driver software (e.g., 6ES7870-1AA01-0YA0).

Q: What additional purchases are required to use this module?

A: Yes. In addition to the module itself, you will also need:

Interface Module: Select the corresponding interface module (e.g., IF963) based on the physical interface type (RS232, TTY, RS422/485). This needs to be ordered separately.

Software driver: If using non-built-in protocols such as Modbus RTU, you need to purchase the corresponding loadable driver.
