The VQ4101-5W1-Q is a 5-way solenoid valve in the SMC VQ4000 series, featuring 2-position single-electrode control and a resilient seal.
Driven by DC 24V with a power consumption of 0.95W, it boasts IP65 protection and CE certification, and can drive cylinders up to 160mm in diameter. Designed for high-frequency operation, this valve offers long lifespan, high reliability, and supports lubrication-free operation for easy maintenance.
100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support 12-Month Warranty
Core Features
- ✓ Controlling Air Flow: As a 5-way valve, it can change the direction of compressed air flow, thereby controlling the extension and retraction of double-acting cylinders or driving other pneumatic actuators.
- ✓ Achieving High-Frequency Switching: Its pilot-operated structure and flexible seal design support high-frequency, rapid response (single-electric control response time approximately 17ms), suitable for automated production lines requiring frequent on/off switching.
- ✓ Providing High Flow Output: With a Cv value as high as 2.1, it can provide sufficient exhaust volume for cylinders with a maximum bore of 160mm, ensuring rapid and powerful actuator action.
- ✓ Integrated Electrical Protection: The built-in surge voltage suppressor and indicator light absorb the back electromotive force generated when the coil is de-energized, protecting the circuit, and facilitating on-site debugging and troubleshooting.
Technical Specifications
| Brand |
SMC |
| Model / Part Number |
VQ4101-5W1-Q |
| Rated Voltage |
DC24V |
| Power Consumption |
Standard Type: 0.95 W (DC) |
| Operating Pressure Range |
0.2 ~ 1.0 MPa |
| Guaranteed Pressure Resistance |
1.5 MPa |
| Ambient and Fluid Temperature |
-10 ~ 50℃ |
| Connection Diameter |
1/4", 3/8" (Optional, Rc/G/NPT/NPTF thread) |
Frequently Asked Questions
Q: Can this valve be used directly to drive a double-acting cylinder?
A: Absolutely. As a 5-way solenoid valve, it is inherently designed for controlling double-acting cylinders. It controls the extension and retraction of the cylinder piston by switching the exhaust and supply air at the two output ports.
Q: My equipment operates at a very high frequency; is this valve durable?
A: Extremely durable. It uses a resilient seal and pilot-operated structure, with a design life of over 100 million cycles and an extremely fast response time (approximately 17ms), making it ideal for high-frequency automated equipment.
Q: I want to install it on a manifold; does this model come with a base plate?
A: No, a base plate is not included. The VQ4101-5W1-Q is an insert valve and must be used with a dedicated base plate (such as the SS5V4 series) or manifold to connect to the air circuit. If it is used alone, a corresponding single-valve base plate needs to be ordered separately.
