The MGPM25TF-50Z is a thin-film cylinder with a guide rod from the SMC MGP-Z series. It has a 25mm diameter, 50mm stroke, and weighs approximately 1.3kg.
Its core feature is an end-lock function, which maintains the cylinder position even if the air supply is cut off. It employs a sliding bearing structure, capable of withstanding more than twice the lateral load of traditional stop cylinders, providing smooth operation and high non-rotational accuracy. It is widely used in applications requiring safe holding, such as stopping, lifting, positioning, and pushing out of conveyor belts.
100% Original & AuthenticIn-Stock & Fast ShippingExpert Technical Support12-Month Warranty
Core Features
- ✓ High lateral load tolerance: The guide rod structure is specifically designed for lateral loads, ensuring smooth operation and high precision.
- ✓ Compact and lightweight: 24% lighter than the previous series, saving installation space.
- ✓ Easy integration: Built-in magnetic ring allows for direct installation of the switch without a partition.
- ✓ Flexible installation: Supports multiple fixing methods and piping in two directions.
Technical Specifications
| Brand |
SMC |
| Model / Part Number |
MGPM25TF-50Z |
| Cylinder bore |
25 mm |
| Cylinder stroke |
50 mm |
| Operating pressure |
0.15 ~ 1.0 MPa |
| Operating temperature |
-10 ~ 60℃ |
| Piston speed |
50 ~ 500 mm/s |
| Type of thread for the sprue |
G 1/8 |
Frequently Asked Questions
Q: What are the main applications of the MGPM25TF-50Z with end-lock function?
A: Primarily used in workstations requiring safety maintenance. For example, to prevent falls in vertical lifting mechanisms, to stop and position materials when horizontal conveyors stop, and to maintain workpiece position in case of accidental air supply interruption. The end-lock function automatically locks the piston rod when the air supply is cut off, improving equipment safety.
Q: How strong is its lateral load resistance?
A: Very strong. Utilizing an extended guide rod structure, it can withstand more than twice the lateral load of traditional stop cylinders. Suitable for direct use as a lateral pushing, clamping, or stop cylinder, requiring no external guide rails, providing smooth operation and high anti-rotational precision.
Q: What precautions should be taken when installing this type of lockable cylinder? How should the magnetic switch be matched?
A: Two points to note:
Unlocking air pressure: Before use, ensure the air supply pressure meets the unlocking requirements (usually above 0.15MPa), otherwise the lock will not release.
Switch sold separately: The main body has a built-in magnetic ring but does not include a switch. A magnetic switch (such as the D-M9* series) needs to be purchased separately according to the control requirements. It can be directly installed on the two slots of the cylinder without a bracket.
