Allen Bradley 1762-0F4/A A 4-channel analog output expansion module from the MicroLogix series.

Name: Allen Bradley 1762-0F4/A A 4-channel analog output expansion module from the MicroLogix series.
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original Allen Bradley Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

Part Number	1762-0F4/A
Product Type	4-channel analog output expansion module
Product Origin	Malaysia
Shipping Port	Xiamen
Weight	0.517 lbs

Brand :
Allen Bradley

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The 1762-OF4/A is a 4-channel analog output expansion module from Rockwell Automation's MicroLogix series.

Designed specifically for MicroLogix 1100, 1200, and 1400 series programmable logic controllers (PLCs), it converts digital signals from the PLC into continuous analog output signals. This module supports both voltage and current output types and can be widely used in scenarios requiring precise analog signal control, such as variable frequency speed control and valve opening control.

100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support 12-Month Warranty

Bosch Rexroth MS2N03-B0BYN-CMSG1-NNNNN-NN Servo Motor

Core Features

✓ 4-Channel Analog Output: Provides four independent analog output channels, each configurable for either voltage or current output.
✓ Dual Voltage/Current Mode: Supports 0-10V DC voltage output and 4-20mA current output; both types can be used interchangeably on the same module.
✓ 12-bit Resolution: High-precision digital-to-analog conversion ensures smoothness and accuracy of the output signal.
✓ Fast Update Rate: Typical output update time is 2.5 milliseconds, meeting most real-time control requirements.

Technical Specifications

Brand	Allen Bradley
Model / Part Number	1762-OF4/A
Product Series	MicroLogix 1762 Expansion Module
Compatible Controllers	MicroLogix 1100 / 1200 / 1400 Series
Output Points	4 channels, single-ended (unipolar)
Output Type	Voltage: 0-10V DC / Current: 4-20 mA
Resolution	12-bit
Output Update Time	Typical 2.5 ms
Voltage Load Range	>1 kΩ
Current Load Range	0-500 Ω (including wire resistance)
Bus Current Consumption	40 mA @ 5V DC, 165 mA @ 24V DC
Accuracy	±1.17% Full Scale @ -20 to 65°C (B Series Modules Only)
Dimensions (H x W x D)	90 x 40 x 87 mm
Operating Temperature	-20 to 65 °C
Wiring Method	Screw terminal blocks
Recommended Cable	Belden 8761 (shielded)

Frequently Asked Questions

Q: Can the 1762-OF4/A be used to control frequency converters?

A: Yes. The 4-20mA current output of this module is the most commonly used control signal type for industrial frequency converters. Simply connect the output channel to the analog input terminal of the frequency converter, and the PLC program can output a 4-20mA signal to control the motor speed. Note that the load range for the current output is 0-500Ω; ensure the frequency converter's input impedance is within this range.

Q: Can voltage and current outputs be used simultaneously?

A: Yes. Each channel of the 1762-OF4/A can be independently configured as either a voltage or current output without additional jumpers or hardware modifications. For example, channel 0 can be configured to control one device with 0-10V, and channel 1 can be configured to control another device with 4-20mA, achieving mixed output.

Q: How many modules can the 1762-OF4/A expand with?

A: The number of expansion modules depends on the controller model used:

With MicroLogix 1100: Up to 4 expansion modules

With MicroLogix 1200: Up to 6 expansion modules

With MicroLogix 1400: Up to 7 expansion modules

During installation, ensure that the distance between the modules and the system power supply does not exceed 6 module slots, and ensure that the total current consumption does not exceed the controller's bus power supply capacity.
