Allen Bradley 1762-IQ16/A A 16-point digital input expansion module from the MicroLogix series.

Name: Allen Bradley 1762-IQ16/A A 16-point digital input expansion module from the MicroLogix series.
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original Allen Bradley Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

Part Number	1762-IQ16/A
Product Type	16-point relay output expansion module
Product Origin	Malaysia
Shipping Port	Xiamen
Weight	0.51 lbs

Brand :
Allen Bradley

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The 1762-IQ16/A is a 16-point digital input expansion module from Rockwell Automation's MicroLogix series.

Designed specifically for MicroLogix 1100, 1200, and 1400 series programmable logic controllers (PLCs), it increases the number of input points in control systems. This module supports both sink and source wiring at 24V DC, offering flexible compatibility with various sensor types. Its compact design allows for DIN rail or panel mounting, making it suitable for various industrial automation field signal acquisition scenarios.

100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support 12-Month Warranty

Bosch Rexroth MS2N03-B0BYN-CMSG1-NNNNN-NN Servo Motor

Core Features

✓ 16 Digital Inputs: Provides 16 24V DC input channels, each with an independent LED status indicator for easy field diagnostics.
✓ Universal Sink/Source Connections: Supports both Sink and Source wiring methods, compatible with PNP and NPN sensors, requiring no additional adapters.
✓ Dual Isolation Group Design: Divided into two groups (inputs 0-7 and 8-15), each group is mutually isolated, allowing connection to different power supply circuits.
✓ Fast Response: Signal on/off delay of only 8 ms, suitable for control applications requiring rapid response.

Technical Specifications

Brand	Allen Bradley
Model / Part Number	1762-IQ16/A
Product Series	MicroLogix 1762 Expansion Module
Compatible Controllers	MicroLogix 1100 / 1200 / 1400 Series
Input Points	16 digital inputs
Voltage Type	24V DC, Sink/Source
Operating Voltage Range	10…30V DC @ 30°C; 10…26.4V DC @ 55°C
Input Current	8.0 mA (typical @ 24V DC); 12.0 mA (maximum @ 30V DC)
On/Off Delay	8.0 ms (on/off)
Isolation Groups	2 groups (inputs 0-7 and 8-15), inter-group isolation
Bus Current Consumption	70 mA @ 5V DC
Dimensions (H x W x D)	90 x 40.4 x 87 mm
Power Consumption	Maximum 5.4 W @ 30V
Operating Temperature	-20 to 65 °C
Mounting Method	DIN rail or panel mount

Frequently Asked Questions

Q: What types of field devices can the 1762-IQ16/A connect to?

A: This module can connect to various 24V DC discrete signal devices. Typical applications include limit switches, buttons, relay contacts, proximity sensors, and photoelectric sensors. Because it supports both sinking and sourcing wiring, both PNP (sourcing) and NPN (sinking) sensors can be directly connected without additional conversion modules.

Q: Why is the input indicator light on, but the PLC program cannot read the signal?

A: The input indicator light being on only indicates that voltage has been detected at the module input, but it does not mean that the signal has been correctly transmitted to the controller. Common causes include: ① Poor connection of the expansion bus between the module and the controller (check if the flat cable is plugged in tightly); ② The slot in the module's I/O configuration does not match the program address; ③ The point is covered or disabled by other logic in the program. It is recommended to first confirm whether the I/O configuration in the RSLogix 500 software correctly maps the module.

Q: How many modules can the 1762-IQ16/A expand with at most?

A: The number of expansion modules depends on the controller model used:

With MicroLogix 1100: Up to 4 expansion modules

With MicroLogix 1200: Up to 6 expansion modules

With MicroLogix 1400: Up to 7 expansion modules During installation, ensure that the distance between the modules and the system power supply does not exceed 6 module slots.
