OMRON CP1L-EM40DR-D CP1L Series 40-Point I/O Programmable Logic Controller (PLC) CPU Unit

Name: OMRON CP1L-EM40DR-D CP1L Series 40-Point I/O Programmable Logic Controller (PLC) CPU Unit
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original OMRON Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

Part Number	CP1L-EM40DR-D
Product Type	Programmable Logic Controller
Product Origin	China
Shipping Port	Xiamen
Weight	1.2 lbs

Brand :
OMRON

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The CP1L-EM40DR-D is a 40-point I/O programmable logic controller (PLC) CPU unit in Omron's CP1L series.

It operates on a 24V DC power supply and features 24 built-in digital inputs and 16 relay outputs. This model comes standard with an Ethernet communication port and two analog inputs, and supports ladder logic programming via CX-One software. It is a cost-effective, compact automation control core unit.

100% Original & Authentic In-Stock & Fast Shipping Expert Technical Support 12-Month Warranty

Bosch Rexroth MS2N03-B0BYN-CMSG1-NNNNN-NN Servo Motor

Core Features

✓ Built-in Ethernet Communication: Standard Ethernet TCP/IP port for easy connection to host systems or network setup.
✓ Relay Output Type: 16 relay outputs, capable of directly driving AC/DC loads, suitable for applications with low switching frequencies.
✓ Built-in Analog Input: Integrated with 2 analog input channels, allowing analog signal acquisition without additional expansion modules.
✓ Flexible Expansion Capability: Supports up to 3 expansion modules, with a maximum I/O point count of 160, and supports optional communication boards.

Technical Specifications

Brand	OMRON
Model / Part Number	CP1L-EM40DR-D
I/O Points	40 (24 inputs / 16 outputs)
Input Type	DC24V
Output Type	Relay output
Analog Inputs	2 channels
Power Supply	24V DC (20.4~26.4V DC)
Program Capacity	10K steps
Data Memory	32K words
Logic Execution Speed	0.55 µs
Communication Ports	Ethernet ×1 (standard), RS-232C/RS-485 (optional communication board)
Dimensions	150 (W) × 90 (H) × 85 (D) mm
Mounting Method	DIN rail or base plate mounting
Operating Temperature	0°C to 55°C

Frequently Asked Questions

Q: What types of equipment is the CP1L-EM40DR-D mainly used in?

A: It is suitable for small to medium-sized automated equipment that requires Ethernet communication but has a low switching frequency, such as packaging machinery, textile machinery, HVAC control, conveyor belt systems, and peripheral equipment for injection molding machines. Its relay output can directly drive AC loads, eliminating the need for intermediate relays.

Q: What software is used for programming? Does it support offline simulation?

A: Use the Omron FA integration toolkit CX-One (which includes CX-Programmer). It supports offline simulation, allowing you to simulate ladder logic program execution on a computer, debug the logic, and then download it to the PLC.

Q: Can the CP1L-EM40DR-D be expanded with more I/O points?

A: Yes. It can connect to up to 3 CP1W series expansion units (such as digital I/O, analog input/output, temperature input, etc.), with a maximum local I/O point count of 160 points. In addition, RS-232C or RS-485 serial communication boards are available as options.
