SMC MGPA50TF-25Z-XC35W MGP-Z Series Compact Guided Cylinder

Name: SMC MGPA50TF-25Z-XC35W MGP-Z Series Compact Guided Cylinder
Availability: InStock

✔ IN STOCK ✔ New Original

Delivery time: Shipped in 3 days after payment
Condition: Brand New & Original SMC Factory Sealed
Warranty: 12 Months Standard Warranty
Quality Guarantee: 30-Day Return and Exchange Policy

Part Number	MGPA50TF-25Z-XC35W
Product Type	Compact Guided Cylinder
Product Origin	China
Shipping Port	Xiamen
Weight	6.61 lbs

Brand :
SMC

Inquiry now

Product categories

how can we help you

You can contact us any way that is convenient for you. We are available 24/7 via email or telephone.

New Products

Product Details

The MGPA50TF-25Z-XC35W is a thin-profile cylinder with a guide rod from SMC's MGP-Z series. It has a 50mm bore and a 25mm stroke, and is a basic model in this series, operating in a double-acting mode.

This cylinder features a high-precision ball bushing guide mechanism, offering higher motion accuracy and stronger resistance to lateral loads compared to versions with sliding bearings or ordinary ball bearings. Therefore, it is ideally suited for automation applications requiring precise positioning and high rigidity.

To reduce impact and achieve smooth operation, this model is equipped with air cushioning devices at both ends. Furthermore, as a "thin" cylinder, its compact design, with optimized end plates and guide rods, achieves significant space savings and weight reduction, with approximate dimensions of 148mm wide and 117mm high.

100% Original & AuthenticIn-Stock & Fast ShippingExpert Technical Support12-Month Warranty

Bosch Rexroth MS2N03-B0BYN-CMSG1-NNNNN-NN Servo Motor

Core Features

✓ Precise Guidance: Built-in high-precision ball bushings provide excellent resistance to lateral loads and motion accuracy.
✓ Smooth Action: Air cushioning at both ends ensures smoother piston movement and reduces impact.
✓ Space Saving: Compact design enables efficient linear motion even in confined spaces.
✓ Dual-Acting Drive: Compressed air drives the piston in both directions, completing the extension and retraction actions.

Technical Specifications

Brand	SMC
Model / Part Number	MGPA50TF-25Z-XC35W
Cylinder bore	50 mm
stroke	25 mm
Port size	G 1/4
Actuation mode	Double-acting
Guide type	High-precision ball bushing
Buffering method	Pneumatic buffer at both ends
Dimensions (approx.)	Width 148 mm, Height 117 mm, Length 64 mm

Frequently Asked Questions

Q: What scenarios is this cylinder suitable for?

A: It is ideal for automated equipment requiring high-precision linear motion and a certain level of torsional resistance, such as precision assembly, positioning, clamping, and transfer processes.

Q: What precautions should be taken when installing this cylinder?

A: It is important to provide clean, dry compressed air that meets specifications and ensure the flatness and rigidity of the mounting surface to achieve its high-precision guiding performance. Also, its dimensions (148mm wide x 117mm high) should be considered to allow sufficient installation space.

Q: What are its mounting accessories and interfaces?

A: This model has a G 1/4 port size; corresponding connectors and tubing should be selected. For specific installation methods and optional accessories (such as switches and mounting brackets), please refer to the SMC official selection manual. You can confirm the details by looking for special suffixes such as "XC35W" in the model number.
